Description

Mini-ITX Motherboard with Intel ATOM FSB533Mhz CPU, VGA/ DVI/HDTV, Dual PCIe GbE, USB2.0, SATAII and Audio

Part Number

KINO-ATOM-N270-R10

Price

Request Quote

Manufacturer

IEI

Lead Time

Request Quote

Category

Single Board Computers

Specifications

System Chipset

Intel 945G
Intel 945GSE+ICH7M

Form Factor

Mini ITX

Ethernet Chipset

Realtek 8111CP

Video Chipset

Intel 945GSE

Audio

Realtek ALC655 AC'97 Codec

BIOS

AMI BIOS Label

CPU

Intel Atom Processor N270 1.6GHz with a 533MHz FSB

Digital I/O

8-bit digital I/O, 4-bit input/ 4-bit output

Dimensions

170mm x 170mm

Display Output

VGA integrated in Intel 945GSE; Support HDTV resolution up to 1080i by component interface; 18 bit Dual channel LVDS by Intel 945GSE; DVI-D support by Chrontel Silcon image Sil1362

Ethernet

Dual Realtek PCIe 8111CP GbE Chipsets

Expansion

1 x PCI, 1 x PCIe mini card

Graphic

Intel Generation 3.5 integrated GFX Core 133Mhz

I/O Interface

6 x USB2.0; 2 x SATA; 1 x CF Type II; 4 x RS-232; 1 x IDE; 2 x PS/2 for KB/MS

Infrared Interface

Infrared Interface by pin header

Memory

One 200-pin 400/533 DDR2 SDRAM SO-DIMM supported (system max. 2GB)

Operation Humidity

5% ~95% non-condensing

Operation Temperature

0°C~60°C (32°F~140°F)

Power Consumption

5V@2.89A, 12V@0.04A (Intel Atom N270 with 1GB DDR2)

Power Supply

5V/12V, AT/ATX Support

Processor

Intel Atom

Super IO

ITE IT8712

WDT

Sofware Programmable support 1~255 sec. System reset

Weight

GW:1100g / NW:370 g

Features

DDR2 400/533 SO-DIMM Memory support up to 2GB
Dual Display support by VGA + DVI-D, LVDS + VGA, LVDS + DVI-D
Intel Atom Processor N270 1.6G for ultra low voltage fan-less support
Support 6x USB2.0, 2x SATA, 4x COM
Support PCIe mini Card, PCI slot for expansion

Datasheet

IEI-KINO-ATOM-datasheet.pdf

684 KiB

Download

Extracted Text

Single board computer Mini-ITX SBC with Intel® Atom™ N270 1.6G, VGA/DVI/TV, KINO-ATOM Dual PCIe GbE, USB2.0, SATA and Audio ATX SATA CF Type II Video Output 1: VGA Video Output 2: DVI Video Output 3: LVDS Video Output 4: HDTV/TV Dual display independent by: ATOM CPU LVDS+DVI, LVDS+VGA, DVI+VGA IDE DDR2 533 VGA Dual GbE SO-Dimm ICH7-M Intel 945GSE PCI 1U Chassis LVDS Compatible COM3/4 Mini PCIe SPDIF DIO KB/MS COM1/2 DVI 4 x USB2.0 Audio 2 x USB IR TV-out PCIe Mini Card 32000-083700-RS 19800-000067-RS USB Mini Card HDTVCABLESET-01 Specifications CPU Intel® Atom™ Processor N270 1.6GHz with a 533MHz FSB System Chipset Intel® 945GSE+ICH7M PCIe PCI-E BIOS AMI BIOS Label Intel® N270 1.6G DDR2533 FSB 533 Memory TDP 2.5W One 200-pin 400/533 DDR2 SDRAM SO-DIMM supported (system max. 2GB) Ethernet Dual Realtek PCIe 8111CP GbE Chipsets Features I/O Interface 6 x USB2.0 1. Intel® Atom™ Processor N270 1.6G for ultra low voltage fan-less support 2 x SATA 2. DDR2 400/533 SO-DIMM Memory support up to 2GB 1 x CF Type II 3. Dual Display support by VGA + DVI-D, LVDS + VGA, LVDS + DVI-D 4 x RS-232 4. Support PCIe mini Card, PCI slot for expansion 1 x IDE 5. Support 6x USB2.0, 2x SATA, 4x COM 2 x PS/2 for KB/MS Graphic Intel® Generation 3.5 integrated GFX Core 133Mhz Dimensions (mm) Display Output VGA integrated in Intel 945GSE Support HDTV resolution up to 1080i by component interface 18 bit Dual channel LVDS by Intel 945GSE DVI-D support by Chrontel Silcon image Sil1362 Expansion 1 x PCI, 1 x PCIe mini card Digital I/O 8-bit digital I/O, 4-bit input/ 4-bit output Infrared Interface by pin header Super IO ITE IT8712 Audio Realtek ALC655 AC'97 Codec WDT Sofware Programmable support 1~255 sec. System reset Power Supply 5V/12V, AT/ATX Support Power Consumption: 5V@2.89A, 12V@0.04A (Intel® Atom™ N270 with 1GB DDR2) Temperature: Operation: 0°C~60°C (32°F~140°F) Humidity: Operation: 5% ~95% non-condensing Dimensions: 170mm x 170mm Weight: GW: 1100g / NW: 370 g Ordering Information Packing List Part No. Description Mini-ITX SBC with Intel® Atom™ N270 1.6G, VGA/DVI/TV, Dual 1 x KINO-ATOM single board computer KINO-ATOM-N270-R10 PCIe GbE, USB2.0, SATA and Audio 1 x Dual RS-232 cable (P/N: 32200-028401-RS) CB-USB02-RS Dual USB cable 2 x SATA cable (P/N: 32000-062800-RS) HDTV Cable Set with S-Video, Composite and Component 1 x I/O shielding (P/N: 45014-0008C0-00-RS) HDTVCABLESET-01 Interfaces 1 x Mini Jumper Pack 1 x Utility CD 32100-088600-RS SATA Power cable 1 x QIG(Quick Installation Guide) 32200-000009-RS 44pin 2.5" IDE cable ICP Deutschland GmbH - Tel. 0711-45960030 - Fax 0711-45960050 - www.icp-deutschland.de K I N O - ATO M - V 1 . 0
